1-Port Gigabit GPON Terminal TX-6610 Complies with ITU G.984.1, ITU G.984.2, ITU G.984.3 and ITU G.984.4 provides comprehensive GPON network compatibility Downstream rates of up to 2.488Gbps and upstream rates up to 1.244Gbps Fiber access and gigabit port provide incredibly fast transfer speeds Supports OMCI (ONT Management Control Interface) remote management
What This Product Does TP-LINK’s TX-6610 is a next-generation Gigabit Passive Optical Network (GPON) terminal, ideal for Fiber to The Home solution. It’s an incredibly robust device allowing users to access high-speed internet connections via its GPON port and share it with a Gigabit Ethernet port. With the transmission rates of up to 2.488Gbps, one GPON port and one Gigabit Ethernet port, the TX-6610 provides high-performance forwarding capabilities to ensure smooth VoIP, HD video streaming experiences. CARACTERÍSTICAS DE HARDWARE Interfaz 1 10/100/1000Mbps RJ45 Ports 1 SC/APC Port Botones 1 Power On/Off Button 1 RESET Button Fuente de Alimentación Externa 9VDC/0.6A Estándares Inalámbricos IEEE 802.3, 802.3u, 802.1Q, 802.1p Tasa de Transferencia Upstream:1.244Gbps Downstream:2.488Gbps Dimensiones 4.0*1.5*4.2 in.(102.7 x 37.9 x 106.9mm) Distancia 0~ 20Km Max Estándares GPON ITU-T G.984.1, G.984.2, G.984.3, G.984.4 Módulo Óptico Class C+ Receptor APD-TIA Transmisor DFB Laser Longitud de Onda Upstream:1310nm Downstream:1490nm
